The slim G7SA relay family with forcibly guided contacts is available as a four or six-pole type in various contact combinations and offers reinforced insulation. Terminals are arranged for easy PCB layout. It can be soldered directly to a PCB or used together with the P7SA sockets.

• Forcibly guided contacts
• Conforms to EN 50205
• 6A at 240VAC and 6A at 24VDC for resistive loads
• Reinforced insulation between inputs and outputs and poles
• 4- and 6-pole relays available

Forcibly guided relay for socket or PCB-mounting
